THANK YOU for your purchase of an A-Series Digital Game Camera. Please read this booklet before using the unit. If you should have any questions about this product or any other Moultrie product, please contact us using the information on the back of this booklet. Please register your camera at www.moultriefeeders.com/warranty to activate your warranty.

Overview

QUICK START INSTRUCTIONS

Battery Installation

Open the camera cover and install 8 AA Alkaline or Lithium batteries. Make sure that the (+ and -) polarities match the polarities indicated inside the battery chamber.

Note: Anytime you load or unload batteries, make sure that the camera is OFF. If using 12V DC Power Panel Plug, do not remove internal batteries.

Insert SD Card

You will need to open the front cover to insert an SD memory card. You can insert a SD Card up to 32 GB (not included). Insert the SD card in the direction indicated on the card, until you hear an audible click.
Note: Camera will not operate without an SD memory card installed. Ultra/turbo SD cards are not recommended.

Power ON

Slide the Mode Switch to the Setup position. The battery level will appear on the LCD Display. The camera has powered up.

Mounting with a Strap

Close cover and place camera on a tree or pole approximately 3 ft. high. Thread the mounting strap through the mounting strap slots on the back of the camera and secure.
Hint: If you are mounting camera to cover a trail, face the camera down the trail tilted at a slight downward angle.
Face the camera north or south to avoid over exposure from the sun.
Clear brush away from camera front to avoid false triggers from the wind.

CAMERA SETUP

Power ONSlide the power switch to the ON position. The battery level will appear on the LCD Display for 2 seconds.After 2 seconds, the camera will display the countdown. When the countdown timer reaches “00”, the display will turn off and the camera will OK Capture Mode.If the camera detects that the battery level is 15% or below, the Low Battery screen will appear and the unit will turn off.

To begin modifying the camera settings, slide the switch to the SETUP position. The camera will display the currently set time. Use the UP and DOWN arrow keys to change the currently flashing option. Once setting is adjusted to the desired option, press OK to lock in the setting and move to the next field/option.
Note: while in SETUP mode, the motion sensor will detect movement and illuminate the STATUS LED on the front of the camera for ~1 second. You can use this feature to ensure camera is properly aimed to detect movement in the desired target area.

Setting Time and DateWhile the camera is in the Setup mode, the LCD display will show the time. Press the OK button and the selection will flash. Use the UP/Down buttons to change the selection. Press the OK button to lock in the selection and move to the next selection. Repeat the process to set the year, month and day.Detection Delay Setting
Detection Delay determines the number of minutes between pictures when an animal is detected and remains in range. Press the OK button. Use the Up/Down buttons to choose between (0, 15, 30 sec, 1 or 5 min). Press OK to lock in your selection and move to the next selection.Setting Capture Mode
Use the Up/Down buttons to choose between 5 different modes:
1 Photo/Low Resolution, 1 Photo/High Resolution, 3 Photos/Low Resolution, 3 Photos/High Resolution and High/Low Video. Press OK to lock in your selection and move to the next selection.
The on-screen icons for each mode are shown to the right:

Setting Camera ID
Use the Up/Down buttons to choose between nine different numbers (1-9) to help identify your cameras (i.e. “CAMERA 3” will be marked on the info strip given 3 was selected).
Press OK to lock in your selection and move to the next selection.

Reset Picture Count/Erase Images/Format Card
You can reset the picture count on the camera. Use the Up/Down buttons to choos between Yes or No. Press the OK button to confirm the selection. “Yes” will reset file number to start from 0001 and erase all images stored on the SD card.

NOTE: This will also format your SD card for use in your camera.

Important Battery information

• Only use Alkaline or Lithium batteries. We recommend the use of Energizer batteries.
• Do not mix old and new batteries. Always replace ALL the batteries at the same time.
• When the camera is not in use, please remove the batteries.

Moultrie Limited Warranty

This product has been thoroughly tested and inspected before shipment. It is guaranteed from defects in material and workmanship from the date of purchase for 2 years. Under this limited guarantee we agree to replace or repair free of charge any part or parts which have been found to be defective in original material or workmanship. Should you require in-warranty service, call our Customer Service Department. If your problem cannot be addressed over the telephone, we may need you to send us your defective product plus proof of purchase.
You must register your camera at www.moultriefeeders.com/warranty to activate your 2-year warranty.

Troubleshooting
Please visit www.moultriefeeders.com/contact-us for troubleshooting and helpful tips.

Returns and Repairs

Please visit http://www.moultriefeeders.com/return-policy and complete the form or our Service Department will gladly answer any questions you have. Call 800-653-3334, Monday – Friday, 8:00 AM to 5:00 PM CST.

MOULTRIE MOBILE® COMPATIBILITY

Your camera is compatible with our Moultrie Mobile® cellular service when combined with the Field Modem MV1. Please visit www.moultriemobile.com for more information.

FCC STATEMENT

Note: changes and modifications not expressly approved by the party responsible could void the user’s authority to operate this device.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.

NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.

NOTE: This device complies with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This device generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this device does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

DOWNLOAD RESOURCES

• Moultrie A-Series Game Camera [pdf] User Manual A-Series, Trail Camera, Game Camera, MCG-13202, MCG-13212, MCG-13201, A-30, A-30i, A-35, 12012016
• Read more: https://manuals.plus/moultrie/a-series-game-camera-manual#ixzz7dZRHoFJ7

FAQ’S

How do you set up a Moultrie a Series game camera?

To connect the camera to a PC computer, turn the camera ON, press the MENU button once to change to SETUP Mode. Connect the USB cord (not included) between the USB out port and the PC computer. The computer will recognize the camera as a removable drive.

How do you reset a Moultrie a series camera?

Perform a hard reset on your camera.
Remove the batteries and the SD card from the camera. With the batteries and SD card removed, turn the camera on for one minute (either use On, Quick Start, or Custom Start modes). After one minute is up, turn the camera back off, and insert the batteries and the SD card.

Why wont my Moultrie take pictures?

Why wont my Moultrie take pictures?
Check the Batteries
Most battery-powered trail cameras will last over time, but sometimes the batteries fail for several reasons. Luckily, this issue is a quick fix as long as you have fresh batteries on hand. Make sure you’re using the proper kind of batteries and install them correctly.

How do I turn my camera on and off?

The A-Series Game Camera is turned on and off by sliding the Mode Switch to the Setup position.

How do I take a picture?

To take a picture, slide the Mode Switch to the Capture position. When you hear a beep, the picture has been taken. If you are using the 12V DC Power Panel Plug, make sure that the plug is connected before you turn on the camera.

Why does my Moultrie camera keep shutting off?

The internal battery calculators inside game cameras are calibrated to read the voltage put out by alkaline or lithium batteries. Since rechargeables have a lower voltage, the camera will tend to shut itself off when these batteries still have a charge because it thinks the batteries are dead due to their low voltage.

How do you test a Moultrie camera?

Connect your camera to Moultrie Mobile.
Turn your camera to ON. You should see the BATTERY and SD CARD lights illuminate to show status. Green BATTERY and SD CARD lights indicate they are good.

Why does my Moultrie camera Say no signal?

If the signal was weak to start with, then low batteries can make it even worse. Pro Tip: If your batteries are getting low then it is best to replace them. Lithium batteries work better than alkaline batteries in the cold weather and will typically last longer in general.

Why is my Moultrie camera taking black photos at night?

Your Moultrie Trail Camera takes impressive photos of wildlife in the great outdoors. Should you start seeing black night photos, or pink daytime photos, it’s time for an infrared (IR) filter reset. The first step to seeing clearer photos is to confirm you are using Moultrie recommended batteries and SD Card.

Can you watch a Moultrie camera from your phone?

There are various ways to connect your Moultrie camera to your mobile device. You can use SD card readers, USB cable, Bluetooth, WiFi, and more. Some of these solutions are more effective than others, so it’s essential to research your device beforehand.

How do I connect my Moultrie camera to my modem?

Plug the micro USB end of the cable into your Moultrie game camera’s micro USB port, ensuring the rubber gasket fits snugly in the opening. Connect the other end of the USB cable into the Field Modem.
NOTE: Before mounting the equipment, we recommend you ensure the cable is inserted properly.

How do I know if my Moultrie camera is working?

Ensure your camera is Active on your account. Once activated, go to the Devices tab from your gallery page and you should see your camera listed if it has been activated.

Moultrie A-Series Game Camera
www://moultriefeeders.com/

IMPORTANT! READ BEFORE YOU START:

• • • • • • • • We recommend that you go through the entire set up process at home to ensure your camera is operating as expected and images are transmitting prior to taking to the field for use.
• You must have an ACTIVE Moultrie Mobile account to operate camera and retrieve images. Log on to MoultrieMobile.com to set up an account or use the free Moultrie Mobile app. Plan purchased from Moultrie at time of activation.
• 12 AA batteries and a compatible SD card are required; we recommend an 8GB or smaller Class 10 SD card.
  NOTE: See page 3 for important battery information.
• Each time you insert an SD card, be sure to format the SD card in your camera to ensure it will work properly. See page 5 for instructions on how to format SD card.
• 4G LTE coverage is required. Go to MoultrieMobile.com to verify coverage in your location.

Please register your camera at www.MoultrieFeeders.com/warranty to activate your warranty.

1. ACCOUNT SET UP AND CAMERA ACTIVATION

SET UP MOULTRIE MOBILE ACCOUNT (Skip this step if already a Moultrie Mobile customer)

Go to MoultrieMobile.com and click REGISTER NEW ACCOUNT or go to the Moultrie Mobile app and click SIGN UP to get started.

IMPORTANT: After submitting your registration, you will receive an email. You will not be able to log in to your account until you have confirmed your registration through this email. Please check your spam, clutter or junk folders for this email.

• Log-on to your Moultrie Mobile account via app or website.
• From the MY ACCOUNT section, select “Activate Device” and follow the on-screen instructions.
  — The Serial Number and Modem ID can be found on the sticker inside of the camera above the battery compartment.
  — If activating mid-billing cycle, the amount owed at activation as well as the number of pictures purchased will be prorated. The next billing cycle will reflect full monthly payment and number of pictures for the plan chosen.
• Click PURCHASE to complete activation of camera.

NOTE: It can take several hours for the device to become active on the cell provider’s network. During this time, the device will not be able to connect to the server. Please keep trying. If after 24 hours your device has not successfully connected to the server, please contact customer service by visiting the “Support” section from the Moultrie Mobile website or app.

2

2. INSTALL BATTERIES

Open camera housing and install 12 AA batteries.

Important Battery Information

• Only use alkaline or lithium batteries. We recommend the use of Moultrie alkaline batteries or Energizer™ lithium batteries for optimum performance.
• Do not mix old and new batteries. Always replace ALL the batteries at the same time.
• Do not mix different brands of batteries or alkaline and lithium batteries.
• When the camera is not in use, please remove the batteries.
• DO NOT USE RECHARGEABLE BATTERIES.
• Be sure batteries are inserted correctly into the battery compartment before powering on the device.

Note: When using lithium batteries, the Moultrie Mobile system may report near full capacity and then quickly drop to indicate low voltage within a short period. This is due to the properties of lithium batteries and is expected behavior.

Note: Internal batteries are required when using an external battery source.

3

3. INSTALL SD CARD

Locate SD card slot on side of camera and insert SD card. Make sure to format the SD card in the camera to ensure proper operation. See page 5 for formatting instructions.

Important SD Card Information

• We recommend that you use an 8GB or smaller Class 10 SD card.
• Do NOT use micro SD cards, SDXC or cards designated as “turbo”, “ultra”, or “super speed”, as the speed required by these cards to operate may cause instability in the cameras.
• We recommend that you have one dedicated SD card for each camera.
• Avoid swapping SD cards between cameras or other digital devices.
• Always format your SD card in the camera before each use.

4

4. FORMAT SD CARD

Power camera on by sliding ON/OFF SWITCH to the ON position.

Anytime the camera’s power switch is flipped from the OFF to ON position, there is a 60-second delay to allow time to format the SD card. Please follow the steps below:

1. Press and hold the FORMAT SD CARD button until the SD CARD LED blinks yellow.
2. Once the card is formatted, the SD CARD LED will turn solid green indicating success.
3. If the SD card LED turns solid red, the SD card was not formatted. Repeat the process until SD card LED is solid green. If the SD card LED does not turn green, try another card.

NOTE: You must format the SD card each time a card is inserted using the above steps.

FORMAT SD CARD VIA APP/WEBSITE

After you’ve completed the initial setup steps above, you will then have the option to format your SD card from the Moultrie Mobile app or website under your Camera Settings. When you elect to format your SD card from the app or website, it will format the next time the camera checks in with Moultrie Mobile.

5

5. LED COLOR DEFINITIONS AND SOLUTIONS

Only LEDs illuminate. If switch or buttons appear to be illuminated, it is due to illumination from surrounding LEDs.

• The BATTERY and SD CARD LEDs will illuminate to show status. Green BATTERY LED indicates power is full and green SD CARD LED indicates card is good. The LED indicators can also be yellow or red. Refer to the table on page 7 for color definitions.
• SIGNAL LED will flash yellow while acquiring signal and turn to solid green if signal is good, yellow if signal is ok, and red if signal is bad.
• SERVER LED will flash yellow while connecting to Moultrie Mobile and turn green when connected. This could take some time, be patient.

Note: To display the status of the Signal, Battery, SD card or Server, you can briefly press CONNECT/STATUS button. Camera will attempt connection to Moultrie Mobile and display LED status.

6

Note: The SIGNAL and SERVER LED’s will flash yellow indicating the camera is connecting to Moultrie Mobile. Once the LEDs stop flashing, the illuminated color will reflect connection status.

7

6. TRANSMIT TEST IMAGE

• Press and hold CONNECT/STATUS button for minimum of 5 seconds.
— Status LEDs will illuminate to display status, refer to table on page 7 for color definitions.
— SIGNAL and SERVER LEDs will flash yellow until connection is established, then illuminate to indicate status. See table on page 7 for color definitions.

• Test image is taken and successfully transmitted once the server LED illuminates green and then all LEDs turn off.

We strongly recommend you confirm receipt of test picture by logging in to your Moultrie Mobile account via the app or website.

MANUALLY TRANSMIT IMAGES

You have the option to transmit any photos captured since the last connection by briefly pressing and realeasing the CONNECT/STATUS button. Once the transmission is complete, all LEDs will turn off.

Note: Upload frequency setting is not affected by manual image transmission.

8

7. CAMERA SETTINGS

Once you have successfully taken and transmitted a test image, go to the website or app to update your camera settings.

Changing settings:

• Go to the “Devices” tab on the Moultrie Mobile website or “Cameras” tab on the app.
• Select “View Cameras” for a list of cameras on account. Select desired camera for update.
• Choose “Camera Settings” on the website or “Edit Settings” on the app. Update camera settings as well as desired upload frequency and press SAVE.

Note: There are icons next to each setting that when clicked will display descriptions and useful tips.

Note: This camera can be set to record video, but video will not transmit to Moultrie Mobile. The video will remain on the SD card.

Important: After camera settings are selected and saved, the settings will be changed on the camera the next time the camera connects to Moultrie Mobile. To manually connect, press the CONNECT/STATUS button to connect to Moultrie Mobile and update settings immediately.

  Confirm status of camera using the LED indicators before leaving your camera.

9

8. UPDATING YOUR FIRMWARE

The XA-6000 / XV-6000 is designed to perform firmware updates automatically.
In the event you need to perform a manual camera firmware update, please follow the below instructions:

UPDATE FIRMWARE MANUALLY

Important: To install firmware manually you must first download the firmware to a clean SD card. Go to MoultrieFeeders.com/firmware-faq for a complete list of firmware and instructions on how to download firmware to an SD card.

• Insert the SD card containing firmware into the SD card slot.
• With camera OFF and no LEDs illuminated, press and hold CONNECT/STATUS button while sliding ON/OFF switch to the ON position.
• Firmware begins updating when all LEDs begin to chase yellow.
• Firmware update successful when, all LED’s turn off, camera reboots, attempts connection to Moultrie Mobile, all LEDs’ turn off.
• Firmware update is unsuccessful if all LEDs turn solid red for 10 seconds and then all LEDs turn off. Please try again.

10

9. MOUNTING CAMERA

Thread mounting strap through slots on back of camera case.

Mount camera to a tree or pole approximately three (3) feet from ground. You may need to adjust for uneven terrain.

For added security, you can attach the camera to a tree with a Master Lock Python™ cable locking system or Moultrie Security Box. Cameras are also equipped with 1/4″-20 inserts for use with Moultrie EZ Tree Mount or Camera Stake accessories, Visit MoultrieFeeders.com to view and purchase mounting accessories.

Tips for Best Photos:

Face the camera North or South to avoid overexposure from the sun.

Clear brush away from the front of the camera to avoid false-movement triggers.

When covering a game trail, face camera looking down the trail instead of directly at it (see graphics).

11

FCC Statements   XV-6000 MCG-13478     XA-6000 MCG-13479
Note: Changes and modifications not expressly approved by the party responsible could void the user’s authority to operate this device.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.

NOTE: This device complies with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This device generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this device does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.

Moultrie Limited Warranty

This product has been thoroughly tested and inspected before shipment. It is guaranteed from defects in material and workmanship from the date of purchase for 2 years. Under this limited guarantee we agree to replace or repair free of charge any part or parts which have been found to be defective in original material or workmanship. Should you require warranty service, visit the support section in the Moultrie Mobile app or at MoultrieMobile.com to contact a technician. Physical damage, alterations or tampering with the equipment is not covered under warranty and will invalidate your warranty.

For questions go to the “Support” section of MoultrieMobile.com or the Moultrie Mobile app.
PRADCO Outdoor Brands • 3280 Highway 31, Ste. B • Calera, AL 35040

11152019

Instructions for Feeder Feet Gen2
THANK YOU for your purchase of the Feeder Feet Gen2. Please read this sheet before operating the unit. If you should have any questions about this product or any other Moultrie product, please contact us using the information on the back of this sheet. To help us to better serve you and to activate your Lifetime Warranty, please submit your warranty information online at http://www.moultriefeeders.com/warranty

WARNING: Do not use feeder feet on hard/slick ground or surfaces without stakes.

1. Remove pin from feeder feet assembly.
2. Slide whole assembly into 1.5” Square tube feeder leg.

3. Insert pin through-hole of leg and adapter.

4. Insert Stake through foot into the ground to the desired depth.

5. Repeat for all three feeder feet.

1. Remove pin from feeder feet assembly.

2. Press in button and remove adapter from feeder feet assembly.

3. Press button and insert foot into square leg (or round leg) until button snaps in place into hole in leg

4. Insert Stake through foot into the ground to the desired depth.

5. Repeat for all three feeder feet.


   WARNING: Do not use feeder feet on hard/slick ground or surfaces without stakes.

Our Service Department will gladly answer any questions you have. www.moultriefeeders.com/support

08132020 / MFG-13455
