mophie juice pack air Manual

ItsManual — Mon, 20 Mar 2023 12:23:24 +0000

mophie juice pack air

Welcome
Thank you for purchasing the mophie juice pack air. You will now be able to travel great distances; be the master of your own destiny, no longer bound by the limitations of your iPhone internal battery. Let’s get juiced!

Package Contains

mophie juice pack air
Micro USB Cable
Pass-through Headphone Adapter

Features

The mophie juice pack air extends the battery life of your iPhone for hours with up to 100% more power to rock, talk, surf, and send and provides a comfortable ergonomic design with the complete protection of a hard shell case.

Here’s a rundown of why the juice pack air is so fantastic:

(Take a breath) Ergonomic, form-fitting, fully protective ultra-impact-resistant case-and-battery in- one for iPhone.
An integrated standby switch allows you to charge (green) whenever you need it. However, in standby mode (red), you still have the full protection of a case.
Sync wirelessly when your iPhone and computer are on the same Wi-Fi network just by flipping the juice pack to charging mode.
Included pass-through headphone adapter allows you to use any style headphones while your iPhone is in the juice pack.
Track battery power at a glance with an integrated four-light LED indicator. You can keep tabs on charging status and current battery life. Know before you go!
The included micro USB cable allows you to charge your phone while refilling your juice pack at the same time. Really, you’ll never need to remove the juice pack from your phone.
Rechargeable for over 500 full cycles. Our case is built to last, letting you do more, longer.
Smart battery technology actually instructs the iPhone to drain power out the juice pack first. When you’re done with the juice pack, you can still have a fully charged iPhone.
The juice pack offers complete protection from top to bottom. No more choosing between protection and power.
Built-in short circuit, over-charge, and temperature protection letting you charge with confidence. Safety First!

Compatibility
The juice pack air was designed and intended solely for the Apple iPhone 5. Please do not attempt to use the product with any other device.

Important
The juice pack comes charged and ready to go but after the initial use, normal charging will take only 2 to 3 hours for maximum power. You can charge it by itself or while the iPhone is inserted.

Charging your juice pack

Connect the included micro USB cable to the bottom of your juice pack. The USB cable can be plugged in to your computer or any power source with a USB out, like the standard USB wall adaptor included with your phone. The LEDs located on the back of the device will blink for 30 seconds to indicate the juice pack has begun charging. When the LEDs stop blinking, it does not mean the case has stopped charging. You can check the charging status by pushing the status button next to the LED lights; the juice pack is fully charged when all four LEDs light up.

Charging your iPhone 5 using the juice pack

If your iPhone is drained of power or if you want to extend the battery life of your phone, slide the iPhone into the juice pack.
Make sure that the connector is securely inserted into the bottom of the phone and the standby switch is turned “On,” or from red to green. When your phone recognizes the juice pack, a battery symbol will appear on the screen and you will hear a chirp from the iPhone. This indicates that the phone is charging and/or using the power from the juice pack rather than from the phone itself. If your iPhone is drained of power, the juice pack will immediately begin charging your phone when flipping from standby to charging mode. If your iPhone is fully charged, the juice pack will act as your primary battery and no power will be lost from the iPhone internal battery until the juice pack is depleted.

Checking the status of the juice pack

To check the battery status of the juice pack, press the status button located on the back of the device. When pressed, the LED lights will illuminate for several seconds. Four LEDs means that the juice pack is fully charged. One LED means that it is almost empty. Know before you go.

Switching your juice pack to standby mode

The switch on the back of the juice back allows you to choose between standby mode and charging mode. Both modes are indicated by a colored dot: red for standby and green for charging. To use your phone’s internal battery, flip the switch to standby mode. When your internal battery is low, flick the switch “On,” or green, and your iPhone will begin charging immediately.
Note: Using the standby switch will give you even more total battery life. The iPhone uses additional power to be on a constant charge. Charging when your battery is low will let you get the most power of out the juice pack.

To keep your juice pack operating to its fullest potential, we recommend the following:

Keep your juice pack dry and away from moisture and corrosive materials.
Do not wash the juice pack with harsh chemicals, soaps or detergents. Just wipe the case with a soft, water-dampened cloth. Wipe the pins gently with a soft, dry cloth.
Recharge your juice pack once every three months when not in use. Charge it for one hour before if you plan on putting it away

Warranty

At mophie, we are dedicated to making the best quality products we can. To back this up, your mophie juice pack is warranted for 1 full year from the date of purchase. This warranty does not affect any statutory rights that you may be entitled to. Keep a copy of your purchase receipt as proof of purchase. Be sure to register your product at mophie. com to activate. Failure to register your product and/ or provide proof of purchase may void the warranty.

Customer Service

Telephone: 1-888-8mophie
International: +1 (269) 743-1340
Web: www.mophie.com/cs
Service Hours: 9am to 6pm M-F EST

Warning

Read all instructions and warnings prior to using this product. Improper use of this product may result in product damage, excess heat, toxic fumes, fire or explosion, for which damages you (“Purchaser”), and not mophie, LLC (“Manufacturer”) are responsible.

Do not store battery in high temperature environment, including intense sunlight heat. Do not place battery in fire or other excessively hot environments.
Be cautious of excessive drops, bumps, abrasions, or other impacts to this battery. If there is any damage to the battery such as dents, punctures, tears, deformities, or corrosion due to any cause, discontinue use. Contact manufacturer or dispose of it in an appropriate manner at your local battery-recycling center.
Do not disassemble this battery or attempt to re-purpose or modify it in any manner.
Do not expose this battery to moisture orsubmerge it in liquid. Keep battery dry at all times.
Do not attempt to charge battery using any method, apparatus, or connection other than the device’s USB connector. For questions or instructions for the various ways to charge the juice pack refer to this manual’s “Charging your iPhone 5 using the juice pack” section.
Do not attempt to replace any part of this battery.
If this battery is intended by Purchaser to be used by a minor, purchasing adult agrees to provide detailed instructions and warnings to any minor prior to use. Failure to do so is sole responsibility of purchaser, who agrees to
indemnify Manufacturer for any unintended use/misuse by a minor.
All batteries have gone through a thorough quality assurance inspection. If you find that your battery is excessively hot, is emitting odor, is deformed, abrased, cut, or is experiencing or demonstrating an abnormal phenomenon, immediately stop all battery use and contact Manufacturer.
For extended storage, first charge your battery for one hour.
Never dispose of batteries in the garbage. Disposal of batteries in the garbage is unlawful under state and federal environmental laws and regulations. Always take used batteries to your local battery-recycling center.

Legal

This battery is meant for use only in conjunction with the appropriate mobile device. Please consult your device packaging to determine whether this battery is compatible with your particular mobile device. Manufacturer is not responsible for any damages to any mobile device incurred through the use of this product.

Manufacturer shall not in any way be liable to you or to any third party for any damages you or any third party may suffer as a result of use, intended or unintended, or misuse of this battery in conjunction with any device or accessory other than the appropriate mobile device for which this battery is designed. Manufacturer will not be responsible for any damages you or any third party may suffer as a result of misuse of this battery as outlined above. If you are responsible for battery use with an unintended mobile device and damages result from such use, you agree to indemnify Manufacturer for any resulting injuries to any third part(ies). mophie, mophie juice pack, juice pack, mophie juice pack air, juice pack air, and the mophie logo are registered in the U.S. Patent and Trademark Office and are registered and pending in other countries. mophie loves you is a pending trademark in the U.S. and other countries. iPhone and Lightning are trademarks of Apple Inc. All rights reserved. Patents: mophie.com/patents. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced technician for help.

CAUTION: To comply with the limits of the Class B digital device, pursuant to Part 15 of the FCC Rules, this device is comply with Class B limits. All peripherals must be shielded and grounded. Operation with noncertified peripherals or non-shielded cables may result in interference to radio or reception.
MODIFICATION: Any changes or modifications of this device could void the warranty.

FAQ
How does it work?

The mophie juice pack has a rechargeable lithium polymer battery inside. When you slide your phone into the case, a connector at the base plugs into the port at the bottom of phone. Flip the standby switch on the back from red to green to start charging your phone. After using up all the power in the juice pack, just recharge it with the included micro USB cable for more on-the-go power. It’s as easy as that.

Why aren’t the LEDs blinking while the juice pack is charging?
After connecting to a power source, the LED status indicator will start blinking to indicate charging. The lights will turn off after 30 seconds allowing for a good night’s rest. Remember to check the status indicator before you disconnect. When all four LEDs are lit, your juice pack is fully charged.
What is the best method for charging my iPhone using the juice pack?
Assuming the iPhone and juice pack are both fully charged, we recommend waiting until your iPhone has 20% battery left. When you’re in the red, flip the standby switch to green and let the juice pack to do the heavy lifting. The iPhone requires more power to charge past 80%, so if you want to get the greatest battery boost from the juice pack, we suggest flipping back to standby mode until your phone battery is low again. This isn’t the end-all-be-all, but we like it.
What is the best method for charging my juice pack?

Connect the juice pack to a power source using the micro USB cable that came with your juice pack. The USB cable can be plugged in to your computer or any “Made for iPhone” power source with a USB out. You do not need to remove your iPhone from the juice pack to charge. Leaving the juice pack on your phone while charging will actually charge both the case and your iPhone simultaneously!

How many charge cycles do you get out of the juice pack? Or, in other words, how long will the juice pack last?

The juice pack is rechargeable for over 500 full cycles. A full cycle is when the case is charged from 0% to 100%. Partial cycles, like charging from 25% to 100%, will not count as a full cycle until all of the partials equal 100%. After 500 cycles, the battery in the juice pack may provide less than 75% of the original capacity. This is normal for any product with a lithium polymer battery.

What are the benefits of switching the juice pack to standby mode?

Using the standby switch will give you the biggest battery boost from the juice pack. The iPhone uses additional power to be on a constant charge, so charging when your phone battery is low will let you get the most from your juice pack.

Can I sync my iPhone while the juice pack is still attached?

Yep. You can sync wirelessly if your iPhone and laptop are connected to the same Wi-Fi network. Just flip your powered juice pack to charging mode or connect to any USB power source. Pretty cool, huh?

What is mophie’s return policy?

mophie reserves the right to claim a 20% restocking fee upon return. Visit mophie.com for a full “Return Policy.”

Will I always receive 100% extra the battery life with my juice pack?

We cannot guarantee that you will receive a 100% battery boost. The amount of additional battery you will receive depends on a variety of factors that are different for every user.

Does the juice pack block the speaker, microphone, camera, or any other ports?

Of course not. In fact, the juice pack is designed to act as a virtual speaker box! Sound is redirected from the bottom of the phone to the front resulting in a richer, fuller sound quality.

Does the juice pack interfere with antenna reception?
Not a chance.

mophie Powerstation go air Manual

ItsManual — Tue, 04 Apr 2023 09:33:44 +0000

powerstation® go air
OPERATING INSTRUCTIONS

mophie power station go air
Thank you for choosing mophie!
Powerful and loaded with features including an easy-to-use digital display, the mophie power station go air can be used to safely jump-start your vehicle or inflate your tires. The mophie power station go air provides portable power so you can charge your phone, tablet, and other electronic devices anywhere! The mophie power station go air also includes a convenient floodlight and emergency light. Compact, versatile and simple to use, the mophie power station go air and all accessories fit neatly in its carrying pouch and is perfect to store in your home or vehicle for everyday use or an emergency need. Never be without a charge, a jump start, or with a flat tire again!

DANGER-CAUTION Read and understand all safety information before using this product. Failure to follow these instructions may result in electrical shock, explosion, the fire which may result in serious injuries, death or property damage.
– When used correctly, lithium-ion rechargeable batteries provide a safe and dependable source of portable power. However, if they are misused or abused, this may result in leakage, burns, fire or explosion, causing personal injury or damage to other devices.
– Misusing or incorrectly connecting your mophie power station go air may cause electric shock to users and damage equipment.
– Do not operate in explosive atmospheres such as in the presence of flammable liquids, gases or dust.
– Remove jump start clamps from vehicle battery after jump starting vehicle.
– Keep your mophie power station go air dry and away from moisture and corrosive materials. The mophie powerstation go air should not be used near water or wet areas such as bathtubs, showers, bathrooms, sinks, swimming pools or basements.
– Do not expose your mophie power station go air to moisture, water, rain, or snow.
– Keep your mophie power station go air away from heat sources, including open flames, radiators, stoves, ovens, and any other devices that produce heat.
– The lithium-ion rechargeable battery used in this charging device may present a risk of fire or chemical burn if mistreated. Do not expose to fire or excessive temperature. Do not expose to heat above 212°F (100°C) or incinerate.
– In the unlikely event of leakage or explosion use sand or a chemical fire extinguisher.
– Your mophie power station go air may become warm under extended high power operation. Do not cover, wrap, or otherwise restrict the mophie power station go air during operation.
– Do not disassemble your mophie power station go air. There are no user-serviceable parts inside. Incorrect reassembly may result in shock or fire hazards.
– Do not drop or subject to strong impacts. Do not operate your mophie powerstation go air if it has received a sharp blow, or has otherwise been damaged in any way.
– Do not puncture, crush or subject to mechanical shock.
– Only charge your mophie powerstation go air by the specified method with the specified charging adapter provided with the unit.
– Do not use any non-mophie-branded accessories with the mophie powerstation go air. Doing so may cause electric shock to users and damage equipment.
– The mophie powerstation go air, along with its accessories, are not toys and should be kept away from children.
– Make sure the jumper cables are fully plugged into the jump start output before trying to jumpstart your vehicle.
– Do not touch red (positive) and black (negative) jumper clamps together at any point.
– Do not insert any foreign object into the ports or openings of your mophie power station go air.
– Do not clean your mophie powerstation go air with harsh chemicals, soaps or detergents. Just wipe the case with a soft cloth.
– Make sure the mophie powerstation go air’s charging ports do not become contaminated with lint or other debris. Use a canned-air type of product periodically to ensure that the port openings are clear.
– When using the air compressor, always check and follow the manufacturer’s recommended pressure. Use caution as the air hose and connectors may get hot after extended use.
– Batteries should be recycled or disposed of as per state and local guidelines.
– Storage: -4°F – 158°F (-20°C – 70°C), Discharge: 14°F – 122°F (-10°C – 50°C), Charge: 32°F – 113°F (0°C – 45°C)

Included items

– mophie power station go air
– Jumper Cables
– Carrying Pouch
– AC Wall Plug
– 24in Air Hose Extension
– Interchangeable Air Nozzle Kit

Jump Start Output
Jump-Start Button
Digital Screen
Pressure Unit Button
USB Outputs
Pressure Settings (+) and (-)
Air Compressor ON/OFF Button
USB ON/OFF Button
Air Hose
Charging Input
Floodlight ON/OFF Button
Floodlight/Emergency Light
24 Inch Air Hose Extension
Jumper Cable Clamps
Wall Charging Adapter
Tapered Air Nozzle
Inflation Needle
Presta Valve Adapter

Operating instructions

IMPORTANT: Before using the power station go air for the first time, fully charge it.
To charge your power station go air, use the provided Wall Charging Adapter, and plug the AC adapter plug into the charge input. Next, connect the AC adapter into a wall outlet. The power station go air will automatically begin charging. When the power station go air is fully charged, all five battery indicator lights will be solid white and the digital screen will indicate 100% charge. (This could take up to 9 hours).

While charging, the digital screen will illustrate the charge percentage of the power station go air. When fully charged, disconnect the cable.

NOTE:
The power station go air is designed to charge between 32°F-113°F (0-45° C). A “TEMP” indicator will be illustrated on the digital display if the power station go air is attempted to be charged outside of this temperature range.

Jump starting your vehicle with the power station go air
1. Plug the jumper cables into the jump start output on the power station go air.

NOTE: Make sure the jumper cables are fully plugged into the jump start output before trying to jump your vehicle.
2. Attach the jumper-cable clamps to the vehicle battery.
– Red clamp on positive terminal (+)
– Black clamp on negative terminal (-)

NOTE:
Once the jumper cable clamps are attached to the vehicle battery, the LCD will display the vehicle battery voltage.
– Do not touch red (positive) and black (negative) clamps together at any point. If the jump start button flashes red, the jumper cables have been connected incorrectly. If this flashing red condition occurs, disconnect the jumper cables from vehicle battery and restart the process from Step 1.
3. Press the “Jump Start” button and wait for a solid green light.

NOTE: A flashing green light indicates safety checks are in progress.
Do not disconnect the jumper cables when the Jump-Start button is illuminated solid green. If you wish to cancel a jump-start attempt, simply press the Jump-Start button again and the solid green light will turn off indicating that the jump-start attempt has been cancelled.
4. Start your vehicle.
NOTE: If your vehicle fails to start after the first attempt, wait 30 seconds and repeat step 3 and step 4. If your vehicle does not start after three attempts, we recommend you consult a certified mechanic.
5. Disconnect the jumper-cable clamps from the car battery.
NOTE:
– The jump start function can not be used in conjunction with USB charging or the air compressor. Please ensure that you have not activated the USB or Air Compressor output modes when attempting to jump-start your vehicle.
– When attempting to jump-start your vehicle, turn off your headlights and any other components that may drain your car battery.
– The power station go air is designed to allow a jump start when used within a safe temperature range. A “TEMP” indicator will be illustrated on the digital display if used outside of the temperature operating range.

Jumpstart troubleshooting tips

Condition	Potential Cause	Solution
The Jump-Start button has been pressed but nothing happens	The USB ON/OFF Button or the Air Compressor ON/OFF Button has been pressed.	The jump start output can not be used in conjunction with the USB output or air compressor modes. Ensure that both USB and AIR Compressor modes are off.
powerstation go air displays a red “BATT TOO LOW” message	The power station go air is not sufficiently charged to jump start the vehicle.	Recharge the powerstation go air and verify at least 50% charged. Then try the jump-starting process again.
powerstation go air Jump Start button flashes red and a SAFETY CHECK FAIL message is displayed	The jumper cables have not been properly connected to the vehicle battery.	Check the jumper cables and ensure that the red clamp is connected to the positive terminal (+) and the black clamp is connected to the negative terminal (-).
power station go air Jump Start button flashes green continuously	The power station go air is waiting to be connected to a battery or a SAFETY CHECK FAIL has been triggered.	Check the jumper cables and ensure they are properly connected to the battery. Check and ensure the vehicle battery voltage is greater than 2.0V. If the SAFETY CHECK FAIL indicator is triggered during the jumpstart process, it is recommended that you consult with a certified mechanic.
powerstation go air displays a blue or red “TEMP” indicator	The powerstation go air has detected a low or high-temperature condition.	Disconnect the power station go air and allow the unit to acclimate to temperature operating range (14°F-122°F) (-10°C – 50°C).
You can not successfully jump-start your vehicle. The powerstation go air displays a vehicle battery voltage greater than 12.0V	The power station go air detects that it is connected to a vehicle battery with a normal starting voltage. This could indicate that another vehicle component is faulty.	It is recommended that you consult with a certified mechanic.
powerstation go air Jump Start and On/Off button flashes red and white	This could occur when attempting to jump-start a vehicle while other electrical components (i.e. headlights, heater, radio, etc.) are on.	Turn off your headlights and any other components that may drain your car battery and try the jump start process again.
	The vehicle battery may be faulty.	It is recommended that you consult with a certified mechanic.

NOTE: If none of these troubleshooting tips work, please consult a certified mechanic for assistance.

power station go air compressor

The powerstation go air comes equipped with a 24 Inch Air Hose Extension and Interchangeable Air Nozzles. Simply twist on the corresponding nozzle to inflate balls, pool floaties, bike tires, and more!
1. Connect the air hose to the tire or use the appropriate nozzle to connect to your inflatable device.
2. Press the (+) or (-) button to set the desired pressure. The pressure measuring units can be changed by pressing the UNIT button.
3. Once the desired pressure has been set, begin inflating by pressing the Air Compressor ON/OFF button. The air compressor will shut off automatically once the pressure has been reached.

NOTE: The air compressor can be started or stopped at any point by pressing the air compressor ON/OFF button. The (+) and (-) may be long pressed to set the desired pressure quickly.
Note: Always check and follow the manufacturer’s recommended pressure. Use caution as the air hose and connectors may get hot after extended use. The power station go air compressor is designed to automatically stop after an extended run-time or if an over-temperature protection setpoint is reached.

Charging an electronic device using the USB output ports

1. Your powerstation go air is compatible with the charging cable provided with your electronic device. To use, plug the Standard USB end of the cable into either one of the two 5V/2.4A USB Output ports located on your powerstation go air.
2. Turn on the USB charging by pressing the USB Power ON/OFF Button on the powerstation go air.

NOTE: The powerstation go air USB charging feature will automatically power off after 30 minutes of inactivity.

mophie smart charge technology

Your powerstation go air contains mophie SMART CHARGE TECHNOLOGY to achieve greater compatibility for charging standard 5V USB electronic devices. mophie SMART CHARGE TECHNOLOGY will allow the powerstation go air to communicate with your electronic device and provide the fastest and safest charge for that device.

Compatibility

Standard 5V USB electronic devices including: mobile phones, tablets, PSP, NDS, MP3, MP4, MP5, Bluetooth, GPS, cameras, and more.

Using your powerstation go air floodlight

The floodlight can be turned on and off by simply pressing and releasing the floodlight ON/OFF button. The first press will turn on the floodlight. A second press will turn on the red emergency light. The third press will turn on SOS flashing red light. The floodlight will automatically turn off after 2 hours of inactivity.

NOTE: Do not look directly into the LED floodlight.

Specifications

Battery Pack Energy: ……………………….. contains a 55500 mWh internal battery
Jump Start: ………………………………………… 12V/600Amps
Air Compressor: ………………………………… 100PSI max
Input: ………………………………………………… 14V/0.85A
USB Output: ……………………………………. 2 x USB 5V/2.4A
Dimensions: ……………………………….. 4.65 x 9.52 x 1.85 inches
Weight: …………………………………….. 2.54 lbs
Operating Temperature (During Charging): …………… 32°F – 113°F (0°C – 45°C)
Operating Temperature: ……………………….. 14°F – 122°F (-10°C – 50°C)

Compliance with FCC Regulation

This device complies with part 15 of the FCC Rules and RSS-Gen of IC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
CAUTION: To comply with the limits of the Class B digital device, pursuant to Part 15 of the FCC Rules, this device must be used with certified peripherals and shielded cables. All peripherals must be shielded and grounded. Operation with non-certified peripherals or non-shielded cables may result in interference to radio or reception.

Limited warranty
At mophie, we are dedicated to making the best quality products. To back this up, this product is warranted for 2 years. For full details regarding warranty terms, exclusions and limitations, please visit: mophie.com/warranty. This warranty does not affect any statutory rights that you may be entitled to. Keep a copy of your purchase receipt as proof of purchase. Be sure to register your product at mophie.com.

Customer Service
Telephone: 1-888-8mophie (1-888-866-7443)
International: +1 (269) 743-1340
Web: www.mophie.com/cs
© 2020 mophie inc. mophie, power station, Stay Powerful, and the mophie logo are trademarks of mophie inc. All rights reserved. Patents: mophie.com/patents.

Mophie Powerstation Flashlight Manual

ItsManual — Sun, 09 Apr 2023 14:27:08 +0000

Mophie Powerstation Flashlight

IMPORTANT SAFETY INSTRUCTIONS

When used correctly, lithium-ion rechargeable batteries provide a safe and dependable source of portable power. However, if they are misused or abused, this may result in leakage, burns, fire, or explosion, causing personal injury or damage to other devices.
Misusing or incorrectly connecting the power station to a rugged flashlight may cause an electric shock to users and damage equipment.
Do not operate in explosive atmospheres such as in the presence of flammable liquids, gases, or dust.
Remove jump start clamps from vehicle battery after jump starting vehicle.
Keep the power station goes rugged flashlight dry and away from moisture and corrosive materials. The power station goes rugged flashlight should not be used near water or wet areas such as bathtubs, showers, bathrooms, sinks, swimming pools, or basements.
Do not expose the power station to a rugged flashlight to moisture, water, rain, or snow.
Keep the power station goes rugged flashlight away from heat sources, including open flames, radiators, stoves, ovens, and any other devices that produce heat.
The lithium-ion rechargeable battery used in this charging device may present a risk of fire or chemical burn if mistreated. Do not expose to fire or excessive temperature. Do not expose to heat above 212°F (100°C) or incinerate.
In the unlikely event of leakage or explosion use sand or a chemical fire extinguisher.
The power station goes rugged flashlight may become warm under extended high power operation. Do not cover, wrap, or otherwise restrict the power station go rugged flashlight during operation.
Do not disassemble the power station with go rugged flashlight. There are no user-serviceable parts inside. Incorrect reassembly may result in shock or fire hazards.
Do not drop or subject to strong impacts. Do not operate the power station go rugged flashlight if it has received a sharp blow, or has otherwise been damaged in any way.
Do not puncture, crush or subject to mechanical shock.
Only charge the power station goes rugged flashlight by the specified method with the specified charging adapter provided with the unit.
Do not use any non-mophie-branded accessories with the power station go rugged flashlight. Doing so may cause an electric shock to users and damage equipment.
The power station goes rugged flashlight, along with its accessories, are not toys and should be kept away from children.
Make sure the jumper cables are fully plugged into the jump start output before trying to jumpstart your vehicle.
Do not touch red (positive) and black (negative) jumper clamps together at any point.
Do not insert any foreign object into the pores or openings of the power station go rugged flashlight.
Do not clean the power station goes rugged flashlight with harsh chemicals, soaps, or detergents. Just wipe the case with a soft cloth.
Make sure the power station goes rugged flashlight’s charging ports do not become contaminated with lint or other debris. Use a canned-air type of product periodically to ensure that the port openings are clear.
Batteries should be recycled or disposed of as per state and local guidelines.
Storage: -4°F – 158°F (-20°C – 70°C), Discharge: -4°F – 104°F (-20°C – 40°C), Charge: 32°F – 113°F (0°C – 45°C)

SAVE THESE INSTRUCTIONS

Charging your power station go rugged flashlight IMPORTANT:

Before using the power station goes rugged flashlight for the first time, fully charge it (so that pressing any button lights up all four LEDs on the LED Battery Indicators).
To charge the power station goes rugged flashlight, connect the provided USB Wall Charger with the provided USB Type-C Cable. Next, connect the USB Wall Charger into a wall outlet; and the USB Type-C Cable tip into the power station goes rugged flashlight. The power station goes rugged flashlight will automatically begin charging. When the power station goes rugged flashlight is fully charged, all four battery indicator lights will be solid white. (This could take up to 7 hours). When fully charged, disconnect the cable.
NOTE:

Blinking light indicates recharging. Solid lights indicate fully charged.
The power station goes rugged flashlight is designed to charge between 32°F-113°F (0-45°C). The battery indicators will rapidly flash if the power station goes rugged flashlight is attempted to be charged outside of this temperature range.

Figure 1

The LED flashlight has a low and high beam mode. Press the flashlight power ON/OFF button once to turn on low beam mode. Press the button a second time to turn on high beam mode.
Figure 2

The Work Light / Emergency Light can be turned on/off by pressing the Work Light / Emergency Light Power ON/OFF button. The first press will turn on the work light. A second press will turn on the red emergency light. The third press will turn on SOS flashing red light.
NOTE:

The flashlight and work light will automatically turn off after 2 hours of inactivity.
Do not look directly into the LED lights

Figure 3

1. Plug the jumper cables into the jump-start output on the power station go rugged flashlight.
NOTE: Make sure the jumper cables are fully plugged into the jump-start output before trying to jump-start your vehicle.
Figure 4

2. Attach the jumper cable clamps to the vehicle battery.

Red clamp on positive terminal (+)
Black clamp on negative terminal (-)
NOTE:
Do not touch red (positive) and black (negative) clamps together at any point. If the jump start
button flashes red, the jumper cables have been connected incorrectly. If this flashing red condition occurs, disconnect the jumper cables from vehicle battery and restart the process from Step 1.

Figure 5

3. Press the “Jump-Start” button and wait for the solid green light.
NOTE: A flashing green light indicates safety checks are in progress.

Figure 6

Do not disconnect the jumper cables when the Jump-Start button is illuminated solid green. If you wish to cancel a jump-start attempt, simply press the Jump-Start button again and the solid green light will turn off indicating that the jump-start attempt has been canceled.

4. Start your vehicle.
NOTE: If your vehicle fails to start after the first attempt, wait 30 seconds and repeat step 3 and step 4. If your vehicle does not start after three attempts, we recommend you consult a certified mechanic.

5. Disconnect the jumper cable clamps from the car battery.
NOTE:

The jump-start function can not be used in conjunction with USB charging. Please ensure that you have not activated the USB output when attempting to jump-start your vehicle.
The powerstation go rugged flashlight is designed to allow a jump-start when used within a safe temperature range.
When attempting to jump-start your vehicle, turn off your headlights and any other components that may drain your car battery.

Jumpstart troubleshooting tips

NOTE: If none of these troubleshooting tips work, please consult a certified mechanic for assistance.

Charging an electronic device using the USB output port
1. Connect the USB Type-C tip of the supplied USB Type-C Cable into the USB Type-C input of your electronic device and connect the Standard USB end of the supplied USB Type-C cable into the powerstation go rugged flashlight USB 5V/2.4A Output port.

Figure 7

2. Turn on the USB charging by pressing the USB Power ON/OFF Button on the powerstation go rugged flashlight.
NOTE:

If your electronic device does not have a USB Type-C Input, the powerstation go rugged flashlight is also compatible with the charging cable provided with your electronic device. To use, plug the standard USB end of the cable into the 5V/2.4A USB Output port located on the powerstation go rugged flashlight.
The powerstation go rugged flashlight USB charging feature will automatically power off after 30 minutes of inactivity.

Warranty

At mophie, we are dedicated to making the best quality products. To back this up, this product is warranted for 2 years. For full details regarding warranty terms, exclusions and limitations, please visit mophie.com/warranty. This warranty does not affect any statutory rights that you may be entitled to. Keep a copy of your purchase receipt as proof of purchase. Be sure to register your product at mophie.com.

Customer Service
Telephone: 1-888-8mophie (1-888-866-7443)
International: +1 (269) 743-1340
Web: www.mophie.com/cs

Specifications

Model………………………………………………………………………….. MPSGRGD-FL36630
Battery Pack Energy………………………………………………….. contains a 36630 mWh internal battery
Jump-Start …………………………………………………………………. 12V/400Amps
Input……………………………………………………………………………. 5V/2A
USB Output………………………………………………………………… 5V/2.4A
Dimensions………………………………………………………………… 2.85 x 10.43 inches
Weight ………………………………………………………………………… 1.15 lbs
Operating Temperature (During Charging) ………….. 32°F – 113°F (0°C – 45°C)
Optimal Discharging Temperature…………………………. -4°F – 104°F (-20°C – 40°C)
Storage Temperature Range……………………………………. -4°F – 158°F (-20°C – 70°C)

Legal

The manufacturer shall not in any way be liable to you or to any third party for any damages you or any third party may suffer as a result of use, intended or unintended, or misuse of this product in conjunction with any device or accessory other than the appropriate device for which this product is designed. Manufacturer will not be responsible for any damages you or any third party may suffer as a result of misuse of this product as outlined above. Purchaser agrees to defend, indemnify, and hold Manufacturer harmless for any claims or damages arising from unintended use or misuse, including use with an unintended device. mophie, powerstation, Stay Powerful, and the mophie logo are trademarks of mophie inc. All rights reserved. Patents: mophie.com/patents.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.

CAUTION: To comply with the limits of the Class B digital device, pursuant to Part 15 of the FCC Rules, this device must be used with certified peripherals and shielded cables. All peripherals must be shielded and grounded. Operation with non-certified peripherals or non-shielded cables may result in interference to radio or reception.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

MODIFICATION: Any changes or modifications of this device could void the warranty.

WEEE DECLARATION: All of our products are marked with the WEEE symbol; this indicates that this product must NOT be disposed of with other waste. Instead, it is the user’s responsibility to dispose of their waste electrical and electronic equipment by handing it over to an approved re-processor, or by returning it to mophie for reprocessing. For more information about where you can send your waste equipment for recycling, please contact mophie, inc. or one of your local distributors.

Customer Service
Telephone: 1-888-8mophie (1-888-866-7443)
International: +1 (269) 743-1340
Web: www.mophie.com/cs
mophie, power station, Stay Powerful, and the mophie logo are trademarks of mophie inc.
All rights reserved. Patents: mophie.com/patents. USB-C is a trademark of the USB Implementers Forum.
314-00881-A

mophie B08H6L78PK 15W Wireless Charging Pad Manual

ItsManual — Mon, 24 Apr 2023 10:33:50 +0000

mophie B08H6L78PK 15W Wireless Charging Pad

Warranty

At mophie, we are dedicated to making the best quality products. To back this up, this product is warranted for 2 years. For full details regarding warranty terms, exclusions and limitations, please visit: mophie.com/warranty. This warranty does not affect any statutory rights that you may be entitled to. Keep a copy of your purchase receipt as proof of purchase. Be sure to register your product at mophie.com.

Customer Service

Telephone: 1-888-8mophie (1-888-866-7443)
International: +1 (269) 743-1340
Web: www.mophie.com/cs

IMPORTANT SAFETY INSTRUCTIONS

WARNING

Do not store device in high-temperature environment, including heat caused by intense sunlight or other forms of heat. Do not place device in fire or other excessively hot environments. Exposure to fire or temperature above 212°F (100°C) may cause explosion.
Do not expose the wireless charger to rain or snow.
Do not use the wireless charger in excess of its output rating. Overloading outputs above rating may result in a risk of fire or injury to persons.
Do not disassemble this product or attempt to re-purpose or modify it in any manner.
Do not attempt to replace any part of this device.
For questions or instructions for the various ways to charge this device, refer to the illustrations in this user manual.
Use of a power supply or charger not recommended by mophie may result in a risk of fire or injury to persons.
If this device is accessible to or may be used by a minor, purchasing adult agrees to be solely responsible for providing supervision, instruction, and warnings. Purchaser agrees to defend, indemnify, and hold mophie or Manufacturer harmless for any claims or damages arising from unintended use or misuse by a minor.
All products have gone through a thorough quality assurance inspection. If you find that your device is excessively hot, is emitting odor, is deformed, abraded, cut, or is experiencing or demonstrating an abnormal phenomenon, immediately stop all product use and contact mophie or Manufacturer.
Switch off the wireless charger when not in use. The wireless charger will automatically switch off when disconnected from its wall charger.
To disconnect the charging pad from line voltage, pull the AC adapter from the AC outlet.
The AC outlet shall be installed near the charging pad and shall be easily accessible.
To comply with FCC RF exposure compliance requirements, the wireless charger must be used with a separation distance of at least 20 cm from all persons.

SAVE THESE INSTRUCTIONS

Legal

mophie or Manufacturer shall not in any way be liable to you or to any third party for any damages you or any third party may suffer as a result of use, intended or unintended, or misuse of this product in conjunction with any device or accessory other than the appropriate device for which this product is designed. mophie or Manufacturer will not be responsible for any damages you or any third party may suffer as a result of misuse of this product as outlined above. Purchaser agrees to defend, indemnify, and hold mophie or Manufacturer harmless for any claims or damages arising from unintended use or misuse, including use with an unintended device.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced technician for help.

MODIFICATION: Any changes or modifications of this device could void the warranty.

STATEMENT OF COMPLIANCE
Hereby, mophie declares that the radio equipment wireless charging base is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: http://www.mophie.com/cert_red.

Manufacturer name	ZAGG Inc / ZAGG International
Commercial registration number	91440300683777942X.
Address	910 W Legacy Center Way, Ste. 500, Midvale, Utah 84047 / 103 Shannon Industrial Estate, Shannon Co. Clare, V14 PH21, Ireland
Model identifier	ADS-25FSG-19 19025EPB ADS-25FSG-19 19025EPG
Input voltage	115V / 230V
Input AC frequency	60Hz / 50Hz
Output voltage	19,0V / 19,0V
Output current	1,3A / 1,3A
Output power	24,7W / 24,7W
Average active efficiency	88,0% / 88,0%
Efficiency at low load (10%)	86,0% / 82,0%
No-load power consumption	0,05W / 0,03W
Model identifier	PYS-000133 PYS-000134
Input voltage	115V / 230V
Input AC frequency	60Hz / 50Hz
Output voltage	19,0V / 19,0V
Output current	1,3A / 1,3A
Output power	24,7W / 24,7W
Average active efficiency	88,0% / 88,0%
Efficiency at low load (10%)	88,0% / 85,0%
No-load power consumption	0,03W / 0,06W

WEEE STATEMENT:
All of our products are marked with the WEEE symbol; this indicates that this product must NOT be disposed of with other waste. Instead it is the user’s responsibility to dispose of their waste electrical and electronic equipment by handing it over to an approved re-processor, or by returning it to mophie inc. for reprocessing. For more information about where you can send your waste equipment for recycling, please contact mophie, inc. or one of your local distributors.

Customer Service
Telephone: 1-888-8mophie (1-888-866-7443)
International: +1 (269) 743-1340
Web: www.mophie.com/cs
mophie, Stay Powerful, and the mophie logo are trademarks of mophie inc.
All rights reserved.
Patents: mophie.com/patents © 2020 mophie inc.

mophie Samsung Galaxy S8 Juice pack battery case Manual

ItsManual — Sun, 25 Jun 2023 05:35:10 +0000

Welcome
Thank you for purchasing the mophie juice pack battery case with charge force wireless power, made for Samsung Galaxy S8 and Galaxy S8+. Your juice pack case gives your phone high-impact protection and enough power to go all day without your needing to find a power outlet. With charge force wireless power, recharging your juice pack case and phone couldn’t be any easier — simply place the juice pack case against any mophie charge force wireless charger or use virtually any wireless charging technology.

Package Contains

mophie juice pack battery case made for Samsung Galaxy S8 or Galaxy S8+
Quick-start guide

Features

Your mophie juice pack battery case’s lithium polymer battery extends the battery life of your phone for hours with extra battery whenever you need it, all while providing a comfortable ergonomic design and the complete protection of a hard-shell case.

Here are just some of the reasons why your juice pack case is so great:

Wireless charging — you can simply place
the juice pack case on just about any wireless charging base to immediately begin recharging the phone and case.
The juice pack case is compatible with all mophie charge force mounts for your home, desk, and car, and with any Qi-compatible wireless charger. (Click here to see mophie charge force products.)
(Take a breath) Ergonomic, form-fitting, fully protective impact-resistant case-and-battery in-one made for Galaxy S8 or Galaxy S8+.
High-impact protection — built to protect against drops and hard falls.
A 3-second press of the status button allows you to charge your phone whenever it needs it; another 3-second press places the juice pack battery back in standby mode. (However, even in standby mode your phone still has full case protection.)
Priority+ wireless charging provides power to your phone first before the juice pack case starts to recharge.
Track battery power at a glance with the integrated four-light LED status indicator. You can keep tabs on charging status and current battery life. Know before you go!
Rechargeable for over 500 full cycles. Our case is built to last, letting you do more, longer.
Built-in short-circuit, over-charge, and temperature protection, so you can charge with confidence. Safety first!

Compatibility

The mophie juice pack battery case made for Galaxy S8 is designed and intended solely for the Samsung Galaxy S8 smartphone. Please do not attempt to use it with any other device.
The mophie juice pack battery case made for Galaxy S8+ is designed and intended solely for the Samsung Galaxy S8+ smartphone. Please do not attempt to use it with any other device. ·
The mophie juice pack battery cases made for Galaxy S8 and Galaxy S8+ will charge wirelessly from any mophie charge force charger or any Qi-compatible wireless charger and are also compatible with other wireless charging technologies, such as those used at coffee houses, on airline flights, in furniture products with wireless charging, and in consumer vehicles that support wireless charging.
The juice pack cases will also wirelessly charge from a Samsung Fast Charge Wireless Charging Pad but will charge at standard wireless charging speeds, not at 1.4x Fast Charging speeds.

Installing your juice pack case

Separate the juice pack case sections.
Slide your Galaxy S8 or Galaxy S8+ phone all the way into the bottom section of the juice pack case so that the case’s USB-C connector is fully inserted into the phone’s USB-C port.
Slide the top section of the juice pack case all the way over the exposed top of the phone so that it snaps into the bottom section of the case.

Charging your phone using your juice pack case

IMPORTANT: Before using your juice pack case for the first time, fully charge it (so that pressing the charge status button lights all 4 LEDs).

To begin charging your phone, press the status button for two seconds. To stop charging your phone, press the status button again for 3 seconds.

Charging your juice pack case (Wireless)
Your juice pack case will charge wirelessly from mophie charge force mounts and all Qi-compatible wireless chargers and can be wirelessly charged by most brands of wireless charging bases. It is also compatible with other wireless charging technologies, such as those used at coffee houses, on airline flights, furniture products with wireless charging, and in consumer vehicles that support wireless charging.

Place the juice pack case against the mophie charge force mount or on the wireless charging base.
Follow the charging base instructions, and make sure that the juice pack case is centered on the charging base. (When charging from a mophie charge force mount the juice pack case will automatically align itself for a proper charge.)

Charging your juice pack case (Wired)
Use the USB-C cable supplied with your Galaxy S8 or Galaxy S8+ phone to charge your juice pack case by connecting it to the USB-C wall adapter included with your phone, or a USB-C car charger. This will allow the case and phone to charge at the fastest speeds available from the adapter or charger.

Checking your juice pack case’s charging status
Momentarily press the status button on your juice pack case and the status LEDs will indicate its charge level. Four LEDs mean that the case is fully charged, while one LED means that it’s almost empty. Know before you go!
Taking care of your juice pack battery case

Keep your juice pack case dry and away from moisture and corrosive materials.
Do not clean your juice pack case with harsh chemicals, soaps, or detergents. Just wipe it with a soft, water-dampened cloth.
Make sure the case’s USB port does not become contaminated with lint or other debris. Use a canned-air type of product periodically to ensure that the port opening is clear.
Recharge your juice pack case once every three months when not in use. If you plan on putting it away, charge it for one hour first.

Warranty

At mophie, we are dedicated to making the best quality products. To back this up, this product is warranted for 2 years from the date of purchase. This warranty does not affect any statutory rights that you may be entitled to. Keep a copy of your purchase receipt as proof of purchase. Be sure to register your product at mophie.com. Failure to register your product and/or provide proof of purchase may void the warranty.

Exclusions & Limitations
Except for the limited warranty expressly set forth or to the extent restricted or prohibited by applicable law, mophie expressly disclaims any and all other warranties express or implied, including any warranty of quality, merchantability, or fitness for a particular purpose, and you specifically agree that mophie shall not be liable for any special, incidental, indirect, punitive, or consequential damages for breach of any warranty of any type on any mophie product. In addition to and without limiting the generality of the foregoing disclaimers, the limited warranty does not, under any circumstances, cover the replacement or cost of any electronic device or personal property inside or outside of the mophie product.

Customer Service
Telephone: 1-888-8mophie
International: +1 (269) 743-1340
Web: www.mophie.com/cs

Warning
Read all instructions and warnings prior to using this product. Improper use of this product may result in product damage, excess heat, toxic fumes, fire, or explosion, for which damages you (“Purchaser”), and not mophie LLC (“Manufacturer”) are responsible.

WARNING! This product contains magnets. To reduce the risk of interference with other electrical equipment, consult your doctor and/or device manufacturer before using this product if you have a pacemaker or other implanted electrical device.

Before using your juice pack case for the first time, fully charge it (so that pressing the charge status button lights all 4 LEDs).
Do not store devices in high-temperature environments, including heat caused by intense sunlight or other forms of heat. Do not place the device in fire or other excessively hot environments.
Be cautious of drops, bumps, abrasions, or other impacts to this device. If there is any damage to the device such as dents, punctures, tears, deformities, or corrosion due to any cause, discontinue use. Contact the Manufacturer or dispose of it in an appropriate manner at your local battery-recycling center.
Do not disassemble this device or attempt to re-purpose or modify it in any manner.
For questions or instructions for the various ways to charge the device refer to the Charging your juice pack case sections of this manual.
Do not attempt to replace any part of this device.
If this device is intended by Purchaser to be used by a minor, purchasing adult agrees to provide detailed instructions and warnings to any minor prior to use. Failure to do so is the sole responsibility of the Purchaser, who agrees to indemnify the Manufacturer for any unintended use/misuse by a minor.
All products have gone through a thorough quality assurance inspection. If you find that your device is excessively hot, is emitting odor, is deformed, abraded, cut, or is experiencing or demonstrating an abnormal phenomenon, immediately stop all product use and contact the Manufacturer.
Before storing your battery for an extended period of time, charge it for one hour.
Never dispose of batteries in the garbage. Disposal of batteries in the garbage is unlawful under state and federal environmental laws and regulations. Always take used batteries to your local battery recycling center.

Legal

The manufacturer shall not in any way be liable to you or to any third party for any damages you or any third party may suffer as a result of use, intended or unintended, or misuse of this product in conjunction with any device or accessory other than the appropriate device for which this product is designed. The manufacturer will not be responsible for any damages you or any third party may suffer as a result of misuse of this product as outlined above. If you are responsible for product use with an unintended device and damages result from such use, you agree to indemnify the Manufacturer for any resulting injuries to any third party(ies).

mophie, juice pack, charge force, Priority+, Stay Powerful, the five-circles design, and the mophie logo is trademarks of mophie inc. Samsung and Galaxy S are trademarks of Samsung Electronics Co., Ltd. `Designed for Samsung’ means that an accessory has been designed to connect specifically to Samsung mobile phones and has been certified by the developer to meet Samsung performance standards. Samsung is not responsible for the operation of this device or its compliance with safety and regulatory standards. The `Qi’ symbol is a trademark of the Wireless Power Consortium. All rights reserved. Patents: mophie.com/patents.

This device complies with part 15 of the FCC Rules and RSS-Gen of IC Rules. Operation is subject to the following two conditions:

This device may not cause harmful interference, and
this device must accept any interference received, including interference that may cause undesired operation.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced technician for help.

MODIFICATION: Any changes or modifications of this device could void the warranty.

This device CONFORMS TO UL STD 60950-1 CERTIFIED TO CSA STD NO. 60959-1, CONFORMS TO UL STD. 2054.

FAQS

Is the case too heavy for a popsocket with a popsocket mount for a car?

Yes it keeps the mophie low and not on the window it’s to heavy and could fall on your leg.

Does the case block access to the headphone jack?

No there is a hole that allows for the headphone jack to plug in.

why doesnt my case charge with any of the cables i bought except the original Samsung one?

Because most likely the other cables aren’t capable of delivering the charge that is required to charge both the 3500 mAh AND the 3300mAh Mophie battery. The original Samsung cable works because it’s delivering the appropriate amount of current to charge both. You could try a cable that’s rated for charging both but most likely the cheap knockoffs aren’t doing the job.

Did anyone find a car mount that will hold this securely?

the vent-type holder does a great job holding mine/ drove lyft and uber for 4 months and only one time did the phone slip out of vent mount

Does this case allow fast wireless charging (10W/2A)?

Yes, your phone will Fast Charge from the Samsung Adaptive Fast Charging wall charger while it’s inside the juice pack case.

This states that “Priority+” allows for fast charging, but does this allow Power Delivery charging?

Yes, it does.

My usb charge port is dead and i use Qi wireless charging only, will yhis charge my phone?

Because your usb port is dead, it might not work because the Mophie is plugged on the bottom into your usb port. Your phone by itself should charge wirelessly.

Will this charger fit into a samsung galaxyS7?

No. This juice pack is not compatible with the Samsung Galaxy S7.

the picture doesn’t seem correct, is t?

NO! I’ve reported it. This is a picture of the Mophie Charge force case which works with the Mophie Charge Force pack. When you order this you receive the Mophie all in one charge case (old style)

Will this case work with an edge to edge tempered glass screen protector?

The mophie juice pack is compatible with most screen protectors.

does this come in any other colors besides black?

You should have a color selection

Is the power key missing on the right to turn off the phone is that normal

Hold down the button on the left side. That turns it on and off.

how do i use a mophie?

Press and hold the button on back of the Mophie for about 10 seconds, the leds should flash in sequence, then go off. You know that it is charging by looking at your battery level in the top right. The battery icon should turn black with a lightning bolt in the middle.

How fast does the case charge the phone? What’s it’s the output?

The juice pack case for the Samsung Galaxy and S8+ supports Qualcomm Quick Charge 3.0, as well as Samsung Fast Charge, and USB Power Delivery. The case is able to accept inputs of 5 volts, up to 3 amps, and 9 volts, up to 2 amps, and they are able to output at the same rate.

mophie Samsung Galaxy S9 & Galaxy S9+Manual

ItsManual — Fri, 04 Aug 2023 04:32:09 +0000

mophie Samsung Galaxy S9 & Galaxy S9

Welcome

Thank you for purchasing the mophie® Juice Pack® battery case with wireless power, made for Samsung Galaxy S9 or Galaxy S9+. Your Juice Pack battery case gives your phone high-impact protection and enough power to go all day without your needing to find a power outlet. Recharging your Juice Pack battery case and phone couldn’t be any easier — simply place the Juice Pack battery case on any mophie wireless charging pad or any other Qi-compatible charger.

Package Contains

mophie Juice Pack battery case made for Samsung Galaxy S9 or Galaxy S9+
Quick-start guide

Features

Your mophie Juice Pack battery case’s lithium-ion polymer rechargeable battery extends the battery life of your phone for hours with extra battery whenever you need it, all while providing a comfortable ergonomic design and the complete protection of a hard-shell case.
Here are just some of the reasons why your Juice Pack battery case is so great:

Wireless charging — you can simply place the Juice Pack battery case on a mophie wireless charging pad or any other Qi-compatible wireless charger to immediately begin recharging the phone and case.
(Take a breath) Ergonomic, form-fitting, fully protective impact-resistant case-and-battery-in-one made for Galaxy S9 or Galaxy S9+.
High-impact protection — built to protect against drops and hard falls.
A 3-second press of the status button allows you to charge your phone whenever it needs it. If you want to stop charging your phone and save some battery for later, just press the button again for 3 seconds. However, even in standby mode your phone still has high-impact protection.
Priority+® charging provides power to your phone first before the Juice Pack battery starts to recharge.
Track battery power at a glance with the integrated four-LED status indicator. You can keep tabs on charging status and current battery life. Know before you go!
Rechargeable for over 500 full cycles. Our case is built to last, letting you do more, longer.
Built in short-circuit, over-charge, over-discharge, and temperature protection, so you can charge with confidence. Safety first!

Compatibility

The mophie Juice Pack battery case made for Galaxy S9 is designed and intended solely for the Samsung Galaxy S9 smartphone. Please do not attempt to use it with any other device.
The mophie Juice Pack battery case made for Galaxy S9+ is designed and intended solely for the Samsung Galaxy S9+ smartphone. Please do not attempt to use it with any other device.
The mophie Juice Pack battery cases made for Galaxy S9 and Galaxy S9+ will charge wirelessly from any mophie wireless charging pad or any Qi-compatible wireless charger, including those used on airline flights and in coffee houses, furniture products, and consumer vehicles.

Installing Your Juice Pack Battery Case

Separate the top and bottom Juice Pack case sections.
Slide your Galaxy S9 or Galaxy S9+ phone all the way into the bottom section of the Juice Pack case so that USB-C connector in the case is fully inserted into the USB-C port in the phone.
Slide the top section of the Juice Pack case all the way over the exposed top of the phone so that it snaps into the bottom section of the case.

Charging Your Phone Using Your Juice Pack Battery Case

IMPORTANT: Before using your Juice Pack battery case for the first time, fully charge it (so that pressing the charge status button lights all 4 LEDs).

To begin charging your phone, press the status button for 3 seconds. The status LEDs will flash in sequence away from the status button 3 times, indicating that the Juice Pack battery has begun charging the phone.

If you want to stop charging your phone and save some battery for later, just press the status button again for 3 seconds. The status LEDs will flash in sequence towards the status button 3 times, indicating that the Juice Pack battery has stopped charging the phone.

Charging Your Juice Pack Battery Case (Wireless)

Your Juice Pack battery case will charge wirelessly from mophie wireless charging pads and all Qi-compatible wireless chargers, including those used on airline flights and in coffee houses, furniture products, and consumer vehicles.

Connect the mophie wireless charging pad or other wireless charging base to a wall outlet according to its instructions.
Place the Juice Pack case on the mophie wireless charging pad or other wireless charging base.
Make sure that the Juice Pack case is centered on the charging base. Charging will begin automatically.

*mophie charge stream pad not included

Charging Your Juice Pack Case (Wired)

Use the USB-C cable supplied with your Galaxy S9 or Galaxy S9+ phone to charge your Juice Pack battery case by connecting it to the USB-C wall adapter included with your phone, or to a USB-C car charger. This will allow the case and phone to charge at the fastest speeds available from the adapter or charger.

*Charging cable not included

Checking Your Juice Pack Battery Case’s Charging Status

Momentarily press the status button on your Juice Pack battery case and the status LEDs will indicate its charge level. Four LEDs means that the case is fully charged, while one LED means that it’s almost empty. Know before you go!

Taking Care of Your Juice Pack Battery Case

Keep your Juice Pack battery case dry and away from moisture and corrosive materials.
Do not clean your Juice Pack battery case with harsh chemicals, soaps or detergents. Just wipe it with a soft, water-dampened cloth.
Make sure the Juice Pack battery case’s USB port does not become contaminated with lint or other debris. Use a canned-air type of product periodically to ensure that the port opening is clear.
Recharge your Juice Pack battery case once every three months when not in use. If you plan on putting it away, charge it for one hour first.

Warranty

At mophie, we are dedicated to making the best quality products. To back this up, this product is warranted for 2 years. For full details regarding warranty terms and exclusions, please visit: mophie.com/warranty. This warranty does not affect any statutory rights that you may be entitled to. Keep a copy of your purchase receipt as proof of purchase. Be sure to register your product at mophie.com. Failure to register your product and/or provide proof of purchase may void the warranty.

Exclusions & Limitations

Except for the limited warranty expressly set forth or to the extent restricted or prohibited by applicable law, mophie expressly disclaims any and all other warranties express or implied, including any warranty of quality, merchantability, or fitness for a particular purpose, and you specifically agree that mophie shall not be liable for any special, incidental, indirect, punitive, or consequential damages of any type on any mophie product. In addition to and without limiting the generality of the foregoing disclaimers, the limited warranty does not, under any circumstances, cover the replacement or cost of any electronic device or personal property inside or outside of the mophie product.
You may have additional warranty rights depending on your country, state, or province. Further, some countries, states, and provinces do not allow the exclusion or limitation of incidental or consequential damages or exclusions or limitations on the duration of implied warranties, so the above may not apply to you. If any provision of the warranty is found unlawful, void, or unenforceable, that provision shall be deemed severable and shall not affect any remaining provision.

Customer Service

Telephone: 1-888-8mophie
International: +1 (269) 743-1340
Web: www.mophie.com/cs

Warning

Read all instructions and warnings prior to using this product. Improper use of this product may result in product damage, excess heat, toxic fumes, fire, or explosion, for which damages you (“Purchaser”), and not mophie llc (“Manufacturer”) are responsible.

Before using your Juice Pack case for the first time, fully charge it (so that pressing the charge status button lights all 4 LEDs).
We recommend that you reprogram your phone’s fingerprint sensor after you install the phone in the Juice Pack case.
Your phone’s NFC performance may be affected while it is installed in the Juice Pack case.
Do not store device in high-temperature environment, including heat caused by intense sunlight or other forms of heat. Do not place device in fire or other excessively hot environments.
Be cautious of drops, bumps, abrasions, or other impacts to this device. If there is any damage to the device such as dents, punctures, tears, deformities, or corrosion due to any cause, discontinue use. Contact Manufacturer or dispose of it in an appropriate manner at your local battery-recycling center.
Do not disassemble this device or attempt to re-purpose or modify it in any manner.
For questions or instructions for the various ways to charge the device refer to the Charging Your Juice Pack Case sections of this manual.
Do not attempt to replace any part of this device.
If this device is accessible to or may be used by a minor, purchasing adult agrees to be solely responsible for providing supervision, instruction, and warnings. Purchaser agrees to defend, indemnify, and hold Manufacturer harmless for any claims or damages arising from unintended use or misuse by a minor.
All products have gone through a thorough quality assurance inspection. If you find that your device is excessively hot, is emitting odor, is deformed, abraded, cut or is experiencing or demonstrating an abnormal phenomenon, immediately stop all product use and contact Manufacturer.
Before storing your battery for an extended period of time, charge it for one hour.
Never dispose of batteries in the garbage. Disposal of batteries in the garbage is unlawful under state and federal environmental laws and regulations. Always take used batteries to your local battery-recycling center.

Legal

Manufacturer shall not in any way be liable to you or to any third party for any damages you or any third party may suffer as a result of use, intended or unintended, or misuse of this product in conjunction with any device or accessory other than the appropriate device for which this product is designed. Manufacturer will not be responsible for any damages you or any third party may suffer as a result of misuse of this product as outlined above. Purchaser agrees to defend, indemnify, and hold Manufacturer harmless for any claims or damages arising from unintended use or misuse, including use with an unintended device.

mophie, Juice Pack, Priority+, Stay Powerful, mophie loves you, the five-circles design, and the mophie logo are trademarks of mophie inc. Samsung and Galaxy are trademarks of Samsung Electronics Co., Ltd. ‘Designed for Samsung’ means that an accessory has been designed to connect specifically to Samsung mobile phone and has been certified by the developer to meet Samsung performance standards. Samsung is not responsible for the operation of this device or its compliance with safety and regulatory standards. The ‘Qi’ symbol is a trademark of the Wireless Power Consortium. USB-C is a trademark of USB Implementers Forum. All rights reserved. Patents: mophie.com/patents.

Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced technician for help.

MODIFICATION: Any changes or modifications of this device could void the warranty.

WEEE DECLARATION
All of our products are marked with the WEEE symbol; this indicates that this product must NOT be disposed of with other waste. Instead it is the user’s responsibility to dispose of their waste electrical and electronic equipment by handing it over to an approved re-processor, or by returning it to mophie, inc. for reprocessing. For more information about where you can send your waste equipment for recycling, please contact mophie, inc. or one of your local distributors.

mophie Global Powerstation Hub Manual

ItsManual — Fri, 08 Sep 2023 18:03:59 +0000

global power station ®hub
Portable battery hub with interchangeable AC power prongs
Compatible with Qi-enabled devices, smartphones, tablets, and other USB devices.


USB-C PD FAST-CHARGE	INTERCHANGEABLE AC POWER PRONGS	QUICK CHARGE 3.0	COMPACT AND CONVENIENT
A high-speed 18W fast charge USB-C PD output offers the most efficient charge.	Recharge your powerstation hub in any region.	The high-output USB-A port delivers up to 15W of power to compatible devices.	An ultra-portable design makes it easy to carry the power station hub just about anywhere.

Key Selling Points

Interchangeable AC power prongs make it easy to recharge your powerstation no matter where you are in the world.
Use the USB-C PD port to recharge the power station hub, or use that same port to charge a device at an ultra-fast speed.
Charge multiple devices simultaneously with two USB-A ports, a USB-C PD port, and wireless charging.
A built-in 6,000mAh portable battery keeps your devices charged throughout the day.
A rubberized, non-slip wireless charging surface keeps your device in place while charging.
The ultra-portable design allows the power station hub to fit easily in your bag.
You can also simultaneously charge multiple devices while the hub is plugged into an outlet.

The next generation of universal power.
Learn more at mophie.com/shop/universal-batteries

mophie global powerstation hub

COMPATIBILITY	mophie cases Samsung Galaxy SI Oe, Samsung Galaxy Si 0, Samsung Galaxy SIO+, Samsung Galaxy Note9, Samsung Galaxy S9, Samsung Galaxy S9+, Samsung Galaxy Tab 3, iPad Pro 12.9-inch (2nd gen.), iPad Pro 10.5-inch, iPad Pro 9.7-inch, iPad mini 4, iPhone Xs Max, iPhone Xs, iPhone XR, iPhone X, iPhone 8, iPhone 8 Plus, iPhone 7, iPhone 7 Plus, iPhone SE, iPhone 6s, iPhone 6s Plus, smartphones, tablets, and other USB-C and US13-A devices
WIRELESS CHARGING COMPATIBILITY	Qi-enabled devices.
EXTRA BATTERY HOURS’	Up to 36 hours of extra battery*
BATTERY CAPACITY	6,000mAh
CHARGING PORTS	AC input / USB-C PD Input/Output / USB-A QC Output / USB-A Output
INPUT / OUTPUT CURRENT	AC Input: 100V – 240V, 0.25A USB-C PD Input: 54 – I2V, up to 18W USB-C PD Output: 5V -12V, up to 18W USB-A Output (QC 3.0): 54 – 12V, up to 15W USB-A Output: 5V @ 2.4A
DIMENSIONS	3.31 in x 3.31 in x 1.16 in (84mm x 84mm 29.5mm)
WEIGHT	9 oz (255.15g)
IN THE BOX	global powerstation hub / quick-start guide / North America Adapter / United Kingdom Adapter / Europe Adapter / Australia Adapter / China Adapter /Travel Cap
WARRANTY	2 years
COLOR, FINISH & PART NUMBER	• Black / Plastic 1401102475 I TRVLSTION-VVRLS-6K

Additional Selling Points

mophie uses advanced wireless and battery technology to create safe, reliable products and deliver the quickest charge speeds possible.
Every mophie battery product is tested at three different stages of production to ensure unmatched capacity, efficiency, and build quality, along with reliable, long-lasting performance.
mophie is the #1 brand for Wireless Charging Pads in the U.S.

mophie.com © 2019 mophie inc. *Extra battery estimates based on comparisons with the mAh battery capacities of common consumer electronic devices. The amount of extra battery you receive depends on a variety of factors that are different for every user.1 The NPD Group, Inc., U.S. Retail Tracking Service, Cell Phone Device Protection, Charging Case, Based on Dollars & Units, Jan. 2015-Sept. 2018. The NPD Group, Inc., U.S. Retail Tracking Service, Mobile Power, Portable Power Packs, Based on Dollars, Jan. 2015- Sept. 2018. The NPD Group, Inc., U.S. Retail Tracking Service, Mobile Power, Charging Pad, Wireless, Based on Dollars and Units, Jan. 2017- Feb. 2019. mophie, powerstation, the five-circles design, and the mophie logo are trademarks of mophie inc. iPad, iPad mini and iPhone are trademarks of Apple Inc. The trademark “iPhone” is used in Japan with a license from Aiphone K.K. Samsung and Galaxy S are trademarks of Samsung Electronics Co., Ltd. Qi, and the Qi logo are trademarks of the Wireless Power Consortium. USB-C is a trademark of USB Implementers Forum. All rights reserved. Patents: mophie.com/patents.

mophie Powerstation Plus Powerstation Plus X Manual

ItsManual — Sat, 09 Sep 2023 08:10:51 +0000

powerstation® plus & power station plus XL
Made for Apple and USB devices
USER MANUAL

Welcome
Thank you for purchasing the mophie® powerstation® plus or powerstation plus XL portable battery. Your powerstation plus/powerstation plus XL portable battery is a compact yet powerful mobile charging solution that features a integrated Lightning charging cable for your Apple devices and an additional USB-A port so you can also charge most USB devices and wearables. Wireless input charging (powerstation plus XL only) lets you recharge your portable battery by placing it on any Qi-compatible wireless charger. Now you will be able to travel great distances and be the master of your own destiny, no longer bound by the limitations of your device’s internal battery or by having to bring the right charging cable!

Package contains

powerstation plus or powerstation plus XL portable battery
Quick-start guide

Features

Here’s a rundown of why your powerstation plus or powerstation plus XL portable battery is so great:

High-density, high-output portable battery charges at fast speeds–up to 2.1A.
Integrated charging cable with a Lightning connector–the right cable to charge your Apple device is always with you.
Additional USB-A output port is compatible with most USB devices and wearables.
Wireless input charging (powerstation plus XL only) lets you recharge your portable battery by simply placing it on any mophie wireless charging pad or Qi-compatible wireless charger.
Lightning input port uses your Apple device’s Lightning cable to recharge the powerstation plus/powerstation plus XL portable battery at fast speeds–up to 2.1A with a compatible wall adapter.
Priority+® pass-through charging provides power to a device connected to the integrated Lightning cable before the powerstation plus/ powerstation plus XL portable battery starts to recharge from its Lightning input port.
Track battery power at a glance with the integrated four-light LED status indicator. You can keep tabs on charging status and current battery life. Know before you go!
mophie’s smart adaptive charging technology identifies your connected device and always delivers the fastest, most efficient charging speeds available.
Digital Power Management circuitry provides built-in short-circuit, overcharge, undercharge, and temperature protection. Safety first!

Compatibility

Your powerstation plus/powerstation plus XL portable battery features a integrated Lightning charging cable so you’re always ready to charge your Apple devices. It also has a USB-A port that will work with most USB devices and wearables.

If you experience any issues with charging your particular device, ensure that the powerstation plus/powerstation plus XL portable battery is fully charged and check the FAQ section on this website.
As always, no matter what device you have, carefully read through the Warning section in this manual and in the quick-start guide included with your portable battery before using it.
Wired recharging requires a Lightning cable and a USB wall adapter (not supplied).
The powerstation plus XL portable battery will wirelessly recharge from all mophie wireless charging pads (not supplied) and all Qi-compatible wireless chargers, including those used in coffee houses, furniture, and vehicles.

Charging your portable battery

IMPORTANT: Before using your powerstation plus/ powerstation plus XL portable battery for the first time, fully charge it (so that pressing the charge status button lights all four status LEDs).

Wired charging

Connect the Lightning cable included with your Apple device to your powerstation plus/powerstation plus XL portable battery’s Lightning input port and to a power source with a USB output, such as the wall adapter included with your Apple device.

Wireless charging

(powerstation plus XL portable battery only)

Place the powerstation plus XL portable battery on a mophie wireless charging pad or other Qi-compatible wireless charging base.
Make sure that the powerstation plus XL portable battery is centered on the charging pad as shown in the illustration. Charging will begin automatically.

Charging your device

After you have fully charged your powerstation plus/ powerstation plus XL portable battery, connect it to your device. Your powerstation plus/powerstation plus XL portable battery features a integrated Lightning charging cable, so you always have the right cable with you to charge your Apple devices.

Pull out the Lightning cable from the side of the powerstation plus/powerstation plus XL portable battery as shown below. 2. Connect the cable to your Apple device’s Lightning connector. Press the status button for 3 seconds to begin charging.

Your powerstation plus/powerstation plus XL portable battery also has a USB-A port that is compatible with most USB devices and wearables. Connect the USB cable included with your device to the powerstation plus/powerstation plus XL portable battery’s USB-A port and to your device. Press the status button for 3 seconds to begin charging. You can connect devices to the portable battery’s USB-A port and to its integrated Lightning cable at the same time.

Priority+ pass-through charging

When you’re recharging your powerstation plus/powerstation plus XL portable battery, Priority+ pass-through charging provides power to an Apple device connected to the portable battery’s integrated Lightning charging cable first, before the portable battery starts to recharge. (The portable battery’s USB-A port is disabled during Priority+ pass-through charging.)
Note: If you’re recharging the powerstation plus or powerstation plus XL portable battery from your computer, Priority+ pass-through charging can sync with iTunes using the powerstation portable battery’s integrated Lightning cable.

Checking your portable battery’s charging status Press the status button on your powerstation plus/ powerstation plus XL portable battery and the status LEDs will indicate its charge level. Four LEDs means that the portable battery is fully charged, while one LED means that it’s almost empty. Know before you go!

Taking care of your portable battery

Keep your powerstation plus/powerstation plus XL portable battery dry and away from moisture and corrosive materials.
Do not clean your powerstation plus/ powerstation plus XL portable battery with harsh chemicals, soaps, or detergents. Just wipe the case with a soft cloth.
Make sure the powerstation plus/powerstation plus XL portable battery’s input and output ports do not become contaminated with lint or other debris. Use a canned-air type of product periodically to ensure that the port openings are clear.
Recharge your powerstation plus/powerstation plus XL portable battery once every three months when not in use. If you plan on putting it away, fully charge it (so that pressing the charge status button lights all 4 status LEDs) first.

Warranty

At mophie, we are dedicated to making the best quality products. To back this up, this product is warranted for 2 years from date of purchase. For full details regarding warranty terms and exclusions, please visit: mophie.com/warranty. This warranty does not affect any statutory rights that you may be entitled to. Keep a copy of your purchase receipt as proof of purchase. Be sure to register your product at mophie.com. Failure to register your product and/ or provide proof of purchase may void the warranty.

Exclusions & limitations

Customer service

Telephone: 1-888-8mophie [1-888-866-7443]
International: +1 (269) 743-1340
Web: www.mophie.com/cs

Warning

Before using your powerstation plus/powerstation plus XL portable battery for the first time, fully charge it (so that pressing the charge status button lights all 4 of the status LEDs).
Do not store device in high-temperature environment, including heat caused by intense sunlight or other forms of heat. Do not place device in fire or other excessively hot environments.
The powerstation plus/powerstation plus XL portable battery should be operated only in open-air conditions. It should not be operated in an enclosed, unventilated space such as a carrying bag, pocket, purse, or bedding. Failure to follow these instructions may cause damage to the battery by overheating.
Be cautious of drops, bumps, abrasions, or other impacts to this device. If there is any damage to the device such as dents, punctures, tears, deformities, or corrosion due to any cause, discontinue use. Contact Manufacturer or dispose of it in an appropriate manner at your local battery-recycling center.
Do not disassemble this device or attempt to re-purpose or modify it in any manner.
For questions or instructions about the ways to charge the device refer to the Charging your portable battery section of this user manual.
Do not attempt to replace any part of this device.
If this device is accessible to or may be used by a minor, purchasing adult agrees to be solely responsible for providing supervision, instruction, and warnings. Purchaser agrees to defend, indemnify, and hold Manufacturer harmless for any claims or damages arising from unintended use or misuse by a minor.
All products have gone through a thorough quality assurance inspection. If you find that your device is excessively hot, is emitting odor, is deformed, abraded, cut, or is experiencing or demonstrating an abnormal phenomenon, immediately stop all product use and contact Manufacturer.
Never dispose of batteries in the garbage. Disposal of batteries in the garbage is unlawful under state and federal environmental laws and regulations. Always take used batteries to your local battery recycling center.

Legal

This product is meant for use only in conjunction with the appropriate device. Please consult your device packaging to determine whether this product is compatible with your particular device. Manufacturer is not responsible for any damages to any device incurred through the use of this product.
Manufacturer shall not in any way be liable to you or to any third party for any damages you or any third party may suffer as a result of use, intended or unintended, or misuse of this product in conjunction with any device or accessory other than the appropriate device for which this product is designed. Manufacturer will not be responsible for any damages you or any third party may suffer as a result of misuse of this product as outlined above. Purchaser agrees to defend, indemnify, and hold Manufacturer harmless for any claims or damages arising from unintended use or misuse, including use with an unintended device.
mophie, powerstation, Power for all, Priority+, Stay Powerful, the five-circles design, and the mophie logo are trademarks of mophie inc. Apple and

Lightning are trademarks of Apple Inc. Use of the Made for Apple badge means that an accessory has been designed to connect specifically to the Apple product(s) identified in the badge, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. Please note that the use of this accessory with an Apple product may affect wireless performance. The `Qi’ symbol is a trademark of the Wireless Power Consortium. All rights reserved. Patents: mophie.com/patents.
This device complies with part 15 of the FCC Rules and RSS-Gen of IC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced technician for help.

CAUTION: To comply with the limits of the Class B digital device, pursuant to Part 15 of the FCC Rules, this device must be used with certified peripherals and shielded cables. All peripherals must be shielded and grounded. Operation with non-certified peripherals or non-shielded cables may result in interference to radio or reception.
MODIFICATION: Any changes or modifications of this device could void the warranty.

WEEE DECLARATION

All of our products are marked with the WEEE symbol; this indicates that this product must NOT be disposed of with other waste. Instead it is the user’s responsibility to dispose of their waste electrical and electronic equipment by handing it over to an approved re-processor, or by returning it to mophie inc. for reprocessing. For more information about where you can send your waste equipment for recycling, please contact mophie inc. or one of your local distributors.

CRE-0659-A
